10-Foot Stainless Steel Cage Bank

Made in the USA by Suburban Surgical Company

Price: $6,995

Shipping included. Cages are built to order and typically ship in approximately 4–6 weeks.

This 10-foot stainless steel cage bank gives your veterinary practice a strong, professional, easy-to-clean housing solution built for daily use. It is a practical choice for clinics that want durable cages, efficient patient handling, and a clean setup that supports a smoother workflow.

Cage Layout

  • Top cages: Four cages, each 30" wide x 30" high x 28" deep
  • Bottom cages: Two cages, each 60" wide x 36" high x 28" deep
  • Divider included: Each 60" bottom cage includes a divider to create two smaller cage spaces when needed
  • Depth: All cages are 28" deep
  • Base: This cage bank is on a stationary base

Features of the Stainless Steel Cages

Door

  • Smooth, deburred stainless steel door spokes help eliminate sharp ends
  • Electropolished, removable, ambidextrous stainless steel door can be remounted with hinges on the right side
  • Door extends below the cage floor to help secure paper liners in place
  • Snug fit between the door and cage body helps prevent pinching of an animal’s paws
  • .1875" stainless steel vertical spokes are spaced 1" apart and welded at every intersection to the cross members and frame
  • .3125" stainless steel door frame and cross members are welded together for strength

Latch

  • Stainless steel latch easily disassembles for sanitizing and adjustment
  • .3125" stainless steel latch keeper securely latches the door
  • Heavy 12-gauge stainless steel latch brackets
  • Notched latch connector bar allows for easy opening
  • Heavy 12-gauge stainless steel self-latching door connector is designed to accommodate a padlock for added security

Hinges

  • .3125" stainless steel hinge pins allow for easy door removal
  • Heavy 12-gauge stainless steel die-formed barrel hinges operate smoothly

Body

  • 22-gauge Type 304 stainless steel body is heli-arc welded into one piece for maximum strength
  • .750" coved rear corners on the top and bottom help prevent dirt and bacteria accumulation
  • .750" radius bends on all sides and back create a smooth, easy-to-clean interior surface
  • Distinctive floor design includes a fluid-retaining front lip on all Regal Cages
  • Bottom lip overlaps the lower cage when used in a Regal Cage arrangement

Frame

  • 18-gauge stainless steel die-formed floor support brace keeps the floor rigid for animal comfort
  • 18-gauge stainless steel die-formed rear support helps maintain cage level
  • 18-gauge stainless steel die-formed front frame adds strength and squareness
  • Frame is fitted with weld nuts to attach cage hardware securely

Hardware

  • Stainless steel installation hardware provides maximum strength
  • Vertical molding strips and 14-gauge bolt-on corner plates mount easily
  • Stainless steel truss-head machine screws fasten into the cage’s front-frame weld nuts for secure hardware attachment

Double-Wide Cage Benefits

  • Two smaller doors allow you to use a large cage while requiring less aisle space to fully open the doors
  • 14-gauge stainless steel latch with top and bottom plate latches secures the door in two places
  • Stainless steel channel holds the divider panel in place
  • No center post gets in the way when placing animals in the cage
  • Self-locking door latch secures the door at both the top and bottom

Have questions or ready to order? Call Brad at 877-545-1202. I’ll help you confirm the details and make sure this cage bank is a good fit for your practice.

Save money, simplify your workflow, and grow your bottom line.

Looking for a Different Size?

We also offer larger stainless steel cage banks and a Cat Condo option for feline housing.

```
