Mindray epM 10 Veterinary Monitor with the Sidestream co2

Mindray epM 10 Veterinary Monitor with the Sidestream co2 plug-and-play kit

Physical Dimensions:

• Size: 10.6" x 9.9" x 6.3" (26.9 cm x 25.2 cm x 15.9 cm)

• Weight: 8.8 lb (4.0 Kg)

- Power Requirements:

• Line Voltage: 100 to 240 VAC (± 10%)

• Maximum Current: 2.0 A

• Frequency: 50/60 Hz (± 3 Hz)

• Battery: Rechargeable lithium-ion battery, 4500mAh, ≥ 4 hours run time

• Recharge Time (Power Off): 5 hours to 90%

• Environmental Requirements:

  Temperature:

• Operating: 0 to 40 °C (without AG and CO2 module)

• Operating: 10 to 40 °C (with AG and CO2 module)

• Storage: -20 to 60 °C

  Humidity:

• Operating: 15 to 95% (non-condensing)

• Storage: 10 to 95% (non-condensing)

  Barometric:

• Operating: 427.5 to 805.5 mmHg (57.0 to 107.4 kPa without AG and CO2 module)

• Storage: 120 to 805.5 mmHg (16.0 to 107.4 kPa without AG and CO2 module)

  Interfacing Main Unit:

• AC power connector (1)

• VGA port (1)

• USB 2.0 connector (2)

• Analog output/nurse call/defib. Sync/Serial Port (1)

• Integrated module rack (1) for 2 slots

• Barcode Scanner: Supports 1D and 2D barcode

• Thermal Recorder: 3 traces (paper 50 mm width, 20 m length)

• Network Printer: Support
