Call: 530-722-4977
Americomp AV30HF
Table/X-Ray Generator Combination
(Works with all film, CR, and DR digital systems)
$275.00 per month or $16,995.00 shipping and installation included.
High-frequency imaging
Requires a 35” x 56” floor space
High-Frequency Veterinary Imaging AV30HF
The AV30HF System produces x-ray images with improved resolution and contrast while affording the operator fast, easy technique selection. Compared to conventional 60 Hertz generators, high-frequency technology produces more X-rays in less time.
Exposure time reduction will minimize image blur caused by motion
By producing a more effective kV, HF technology improves penetration power, allowing for lower kV settings. The resulting scatter radiation is minimized, eliminating gray, fogged films. By integrating the generator into the table, there are significant ease of use benefits. Changes in technique settings are quickly facilitated without leaving the table.
Visual information about the settings is conveniently displayed.
Additionally, the integrated generator table concepts significantly reduce floor space requirements and the difficulty of installation.
Systems require only 35” x 56” of floor space. Convenient Light Beam Collimator Provides a high-intensity light field for quick, accurate positioning.
“Soft start” bulb power circuits double bulb life.
The swivel mechanism facilitates table-top procedures. Exceeds federal standards for radiation leakage protection. Shutter actuators are designed for use with lead gloves. Rubber-edged collimator prevents operator head injuries.
Simplex Cassette Tray
Each system includes a Simplex cassette tray. There are no moving parts, so it’s twice as easy to load.
Accepts 8” x 10”, 10” x 12”, and 14” x 17” cassettes in the long or cross direction.
Optional Features − Table-top extension (either end) adds 12” of table length for very large animals or standing lateral views.−Tie-down brackets offer non-manual restraint capabilities.
An out-of-room exposure switch allows you to leave the table when taking exposures.
Warranty:
System: 5-year parts, X-ray tube: 5-year pro-rated.
About Americomp
Since 1987, the quality standards of Americomp have been unsurpassed. Americomp systems remain the affordable choice in today’s marketplace, offering the same long term dependable performance that has become synonymous with the Americomp name.
Equipment Specifications:
Americomp AV30HF Veterinary X-ray System with:
High-Frequency Generator
20 kHz High-Frequency technology
30 kW rating
Technique selection: kVp/mAs
kVp range: 40 – 125
mA range : 50-300, mAs range: 0.5 to 400
Digital mA, kVp and mAs readout
Digital diagnostic readout
Built-in tube protection circuit
UL Classified
Operation from 230-240 VAC, 1 phase electrical service.
Table / Tubestand
Enclosed, integrated radiographic table
Fixed top table: 53 in. x 24 in.
Welded base construction
Variable vertical tube travel
DR holder 06194 replaces grid cabinet, grid, and tray
Angulation indicator and operator handgrips
Footswitch with 20 ft. cord
X-Ray Tube A120
1.0 – 2.0 mm F.S., 140,000 H.U. with 90° horns
Cables A0012
12 ft. high-voltage cables with federal terminations
Collimator A8048-2
Manual collimator with light field
Field light “on” time – selectable 30, 60, 90 or 120 seconds
Easy-to-operate with gloves on
